D620D
Specifications
Selection
Choose a Unit
YOUR STORE
Details
- Application
- Less Than Truckload, Distribution and P&D, Truckload
- Article Number
- 3310
- Tire Size
- 11R22.5
- Compound
- Ply/Star Rating
- 14
- Tread Depth (32nds) (mm)
- 28
- Load Range
- G
- Overall Width (in) (mm)
- 11 279
- Overall Diameter (in) (mm)
- 41.5 1054
- Max. Tire Load Dual (lbs) (kg)
- 5840 2650
- Max. Speed (mph) (km/h)
- 75 121
- Meas. Rim (in) (mm)
- 8.25 210
- Overall Width Loaded (in) (mm)
- 12.1 307
- Static Loaded Radius (in) (mm)
- 19.3 490
- Max. Tire Load Single (lbs) (kg)
- 6175 2800
- Inflation Pressure (psi) (kPa)
- 105 720
- Revolutions Per (mile) (km)
- 497 309
- Application
- Less Than Truckload, Distribution and P&D, Truckload
- Article Number
- 3311
- Tire Size
- 11R22.5
- Compound
- Ply/Star Rating
- 16
- Tread Depth (32nds) (mm)
- 28
- Load Range
- H
- Overall Width (in) (mm)
- 11 279
- Overall Diameter (in) (mm)
- 41.5 1054
- Max. Tire Load Dual (lbs) (kg)
- 6395 2900
- Max. Speed (mph) (km/h)
- 75 121
- Meas. Rim (in) (mm)
- 8.25 210
- Overall Width Loaded (in) (mm)
- 12.1 307
- Static Loaded Radius (in) (mm)
- 19.3 490
- Max. Tire Load Single (lbs) (kg)
- 6940 3150
- Inflation Pressure (psi) (kPa)
- 123 850
- Revolutions Per (mile) (km)
- 497 309
- Application
- Less Than Truckload, Distribution and P&D, Truckload
- Article Number
- 3312
- Tire Size
- 11R24.5
- Compound
- Ply/Star Rating
- 14
- Tread Depth (32nds) (mm)
- 28
- Load Range
- G
- Overall Width (in) (mm)
- 11 279
- Overall Diameter (in) (mm)
- 43.5 1105
- Max. Tire Load Dual (lbs) (kg)
- 6005 2725
- Max. Speed (mph) (km/h)
- 75 121
- Meas. Rim (in) (mm)
- 8.25 210
- Overall Width Loaded (in) (mm)
- 12.1 307
- Static Loaded Radius (in) (mm)
- 20.3 516
- Max. Tire Load Single (lbs) (kg)
- 6610 3000
- Inflation Pressure (psi) (kPa)
- 105 720
- Revolutions Per (mile) (km)
- 475 295
- Application
- Less Than Truckload, Distribution and P&D, Truckload
- Article Number
- 3313
- Tire Size
- 11R24.5
- Compound
- Ply/Star Rating
- 16
- Tread Depth (32nds) (mm)
- 28
- Load Range
- H
- Overall Width (in) (mm)
- 11 279
- Overall Diameter (in) (mm)
- 43.5 1105
- Max. Tire Load Dual (lbs) (kg)
- 6610 3000
- Max. Speed (mph) (km/h)
- 75 121
- Meas. Rim (in) (mm)
- 8.25 210
- Overall Width Loaded (in) (mm)
- 12.1 307
- Static Loaded Radius (in) (mm)
- 20.3 516
- Max. Tire Load Single (lbs) (kg)
- 7160 3250
- Inflation Pressure (psi) (kPa)
- 120 830
- Revolutions Per (mile) (km)
- 475 295
- Application
- Less Than Truckload, Distribution and P&D, Truckload
- Article Number
- 3314
- Tire Size
- 295/75R22.5
- Compound
- Ply/Star Rating
- 14
- Tread Depth (32nds) (mm)
- 28
- Load Range
- G
- Overall Width (in) (mm)
- 11.7 297
- Overall Diameter (in) (mm)
- 40.2 1021
- Max. Tire Load Dual (lbs) (kg)
- 5675 2575
- Max. Speed (mph) (km/h)
- 75 121
- Meas. Rim (in) (mm)
- 9 229
- Overall Width Loaded (in) (mm)
- 12.9 328
- Static Loaded Radius (in) (mm)
- 18.8 478
- Max. Tire Load Single (lbs) (kg)
- 6175 2800
- Inflation Pressure (psi) (kPa)
- 110 760
- Revolutions Per (mile) (km)
- 514 319
- Application
- Less Than Truckload, Distribution and P&D, Truckload
- Article Number
- 3315
- Tire Size
- 285/75R24.5
- Compound
- Ply/Star Rating
- 14
- Tread Depth (32nds) (mm)
- 28
- Load Range
- G
- Overall Width (in) (mm)
- 11.1 282
- Overall Diameter (in) (mm)
- 41.3 1049
- Max. Tire Load Dual (lbs) (kg)
- 5675 2575
- Max. Speed (mph) (km/h)
- 75 121
- Meas. Rim (in) (mm)
- 8.25 210
- Overall Width Loaded (in) (mm)
- 12.3 312
- Static Loaded Radius (in) (mm)
- 19.4 493
- Max. Tire Load Single (lbs) (kg)
- 6175 2800
- Inflation Pressure (psi) (kPa)
- 110 760
- Revolutions Per (mile) (km)
- 499 310
Specialized Features
- Aggressive lug pattern for a solid grip in wet and dry conditions.
- Deep tread helps extend tread life.
- Staggered tread block helps prevent initiation of irregular wear.
- Limited inventory in the following sizes: 11R22.5(16), 11R24.5(14), 11R24.5(16), 295/75R22.5, 285/75R24.5. Contact your local dealer for availability.
